ASTM B424 Inconel Alloy 800 Sheet
Inconel 800 Sheets
-
UNS N08800 Plate
Inconel N08800 Plates
-
1.4876 Plates
WNR. 1.4876 Plates
800 Inconel Plate, 800H Incoloy Alloy Sheet, Alloy 800HT Coils, 800 Inconel® Alloy Plate Suppliers in Mumbai.
Incoloy 800 Sheets are nickel-iron-chromium alloys with good strength and excellent resistance to oxidation and carburization in high-temperature exposure. They have almost the same chemical composition as Incoloy 800H Plates but differ in the amount of carbon present. Incoloy 800 Sheets contain up to 0.1% C, while Alloy 800H contains 0.04 -0.1% C, and Alloy 800HT has 0.06-0.1%C content. These Incoloy 800HT Plates offer superior corrosion resistance even in extreme conditions such as acids or saltwater environments due to their Ni/Cr/Fe ratio of at least 20%. Additionally, they provide excellent creep rupture strength, making them an ideal choice for high-temperature applications such as petrochemical process equipment.
Table of Content
Incoloy 800HT Sheets are widely used in a variety of industries due to their superior mechanical properties and corrosion resistance. They can be found in uses from oil & gas, nuclear power plants, chemical processing plants, and many other industrial applications including heat exchangers, condensers, superheaters, vaporizers, and more.
800 Plate Suppliers, 1.4958 Plates, 800H Incoloy Alloy Plate, 800 Inconel Alloy Coils, Nickel Alloy 800, 800HT Sheet, Grade 800 Inconel Sheets, Inconel® Alloy 800HT Coils, UNS N08810 Sheet, Incoloy Alloy 800H Plate, 800 Incoloy Sheet Manufacturers In India.
Due to their excellent qualities, these sheets have become the material of choice for many manufacturers worldwide who need reliable products with superior performance characteristics. Furthermore, they offer excellent weldability along with good workability which makes them easy to fabricate into complex components.
Our Incoloy 800HT Coils are stocked in a variety of sizes and thicknesses to meet your exact requirements. We have an extensive inventory of these sheets available at competitive prices. At Steel Tubes India, we pride ourselves on providing the best quality Incoloy 800, 800H, and 800HT Sheets that are reliable and long-lasting in all kinds of extreme conditions. Our team is here to help you find the right product for your applications so that you can be sure of superior performance at all times.
Get Incoloy Alloy 800 Plate Suppliers in Mumbai at Factory Price, Wide range of 800H Thin Inconel Sheets as per JIS, AISI, ASTM, GB standard, Inconel Alloy Sheet 800HT Stock, Bulk Stockholders Of 2mm 800 Inconel Sheet In India.
800 Inconel Alloy Sheets Specifications
| Specifications | ASTM B407, ASTM B163, ASTM B358, ASTM B515, ASME SB407, ASME SB163, ASME SB358, ASME SB 515, UNS N08800/10/11 |
| Dimensions | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Size Range |
Cold Rolled : 0.5-6.4 mm Hot Rolled : 3.0–10.0 mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| Tolerances (width / thickness) |
EN 10258/ DIN 59381 EN 10151 EN 10088 |
| Finish | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR) |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Profiling |
Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
Inconel Alloy 800H Sheets Equivalent Material
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN | OR |
| Incoloy 800 | 1.4876 | N08800 | NCF 800 | Z8NC32-21 | NA 15 | ЭИ670 | X10NiCrAlTi32-20 | XH32T |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | Z8NC33-21 | NA 15(H) | ЭИ670 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4859 / 1.4876 | N08811 | NCF 800HT | - | NA 15(HT) | ЭИ670 | X8NiCrAlTi32-21 | XH32T |
Common Types of Inconel Alloy 800HT Sheet & Plate
Incoloy 800 Hot Rolled Sheets
Alloy 800H Cold Rolled Plate
Inconel® Alloy 800HT
Coils
800 Incoloy Sheets & Plates Technical Data Sheet
Inconel Alloy 800 Sheet Standard Size
800H Incoloy Sheet Thickness
Alloy 800HT Plate Weight Chart in Kg
Inconel Alloy 800H Sheet Sizes
800 Inconel Alloy Sheet Price List
| Price List of Inconel Alloy 800 Sheet | Alloy 800H Plate Price in India (INR) | 800HT Inconel® Alloy Sheet Price in USD | Incoloy Alloy 800 Plates Price in UAE (Dirham) |
| 800 Inconel Alloy Sheets Price | ₹ 400-₹ 600 | $ 7.11 USD | 30.43 AED |
| Alloy 800HT Sheet Price Per Kg | ₹ 830-₹ 950 | $ 8.27 USD | 20.02 AED |
| 800HT Inconel Alloy Plates Price | ₹ 200-₹ 300 | $ 5.42 USD | 6.88 AED |
| 16 Gauge Incoloy Alloy 800 Sheet Price | ₹ 350-₹ 650 | $ 6.35 USD | 20.96 AED |
| 24 Gauge Inconel Alloy 800H Sheet Price | ₹ 650-₹ 800 | $ 6.87 USD | 40.92 AED |
| 6mm 800HT Inconel Alloy Plate Price | ₹ 450-₹ 550 | $ 8.86 USD | 30.52 AED |
| 800 Inoloy Alloy Sheet Price | ₹ 1400-₹ 1500 | $ 38.71 USD | 65.03 AED |
| Price of 1mm Inconel® Alloy 800H Sheet | ₹ 1100-₹ 1400 | $ 25.24 USD | 55.28 AED |
| 800HT Inconel Alloy Coils Price | ₹ 500-₹ 900 | $ 8.49 USD | 25.18 AED |
| 800H Incoloy Alloy Plate Price | ₹ 1500-₹ 1801 | $ 35.87 USD | 40.29 AED |
Check 800 Inconel Alloy Sheet Standard Size, Thickness, Weight and 800HT Incoloy Perforated Sheet Price per kg in Mumbai.
Inspection
Surface and Dimension Test, Mechanical Properties Test(tensile Strength, Yield Strength, Elongation, Flaring, Flattening, Bending, Hardness, Impact Test), Chemical Composition Inspection, No-destructive Test, Hydrostatic Test.
Finish Types
- No.4 Finish
- Mirror Finish
- Brushed Finish
- Polished Finishes
- No. 2B – Matte finish
Packing
Bare packing/bundle packing/crate packing/wooden protection at the both sides of tubes and suitably protected for sea-worthly delivery or as requested.
Marking
Our products are packaged to make sure that there’s no damage throughout transit. Just in case of exports, customary export packaging is completed in wooden boxes or cases.
800H Inconel Alloy Sheet Chemical Composition
| Incoloy | 800 | 800H | 800HT |
| Ni | 30-35 | 30-35 | 30-35 |
| Fe | 39.5 min | 39.5 min | 39.5 min |
| Cr | 19-23 | 19-23 | 19-23 |
| Cu | 0.75 max | 0.75 max | 0.75 max |
| Ti | 0.15-0.60 | 0.15-0.60 | 0.25-0.60 |
| Al | 0.15-0.60 | 0.15-0.60 | 0.85-1.20 |
| C | 0.1 max | 0.05-0.1 | 0.06-0.1 |
| Mn | 1.5 max | 1.5 max | 1.5 max |
| S | 0.015 max | 0.015 max | 0.015 max |
| Si | 1.0 max | 1.0 max | 1.0 max |
800HT Inconel Alloy Plate Mechanical Properties
| Density | 7.94 g/cm3 |
| Melting Point | 1385 °C (2525 °F) |
| Tensile Strength | Psi – 75,000 , MPa – 520 |
| Yield Strength (0.2%Offset) | Psi – 30,000 , MPa –205 |
| Elongation | 30 % |
Other Types of Inconel Alloy 800 Sheet & Plate
Inconel Alloy Sheet and Plate
- Inconel Alloy 800 HR Sheets
- 800H Inconel Alloy Sheet Weight Calculator
- UNS N08800 Plates
- Inconel® Alloy 800HT Plate Suppliers in India
- 800 Inconel Alloy Sheet
- 800H Plate Suppliers
- Alloy 800HT Sheet Manufacturer in India
- 800 Sheet
- 800H Plate
- 2mm 800HT Inconel Alloy Sheet
- Incoly Alloy 800 Plate Manufacturer in Mumbai
- Alloy 800H Sheet Manufacturer in Mumbai
- Thin Inconel Alloy 800HT Sheets Stockist
- Incoloy Alloy 800 Cold Rolled Sheets
- Inconel 800H Sheet
- Alloy 800HT Sheet Supplier in Mumbai
- 800 Inconel Alloy Sheets Cut To Size
- 10 Gauge Incoloy Alloy 800H Sheet
- 1.4876 Sheets
- 800HT Inconel Alloy Plate
- 800 Inconel Alloy Sheet Distributors
- 800H Nickel Alloy Plate 10mm
- Inconel 800HT Sheet Suppliers in India
- Incoloy 800 Plate Manufacturer in India
- Alloy 800H Plate Supplier in Mumbai
- UNS N08800 Sheets
- ASME SB407 800HT Inconel Alloy Sheets
- ASTM B407 800 Inconel Alloy Plate
- Alloy 800H Plate
- 800 Inconel Alloy Sheet
- 800HT Inconel Alloy Cold Rolled Plate
- 1.4876 Plate
- 800 Inconel Alloy Checker Plate Dealers
- Incoloy 800H Plates
Inconel Alloy Coils
- 1.4958 Coil
- 800 Incoloy Alloy Coil
- Thin Inconel Alloy 800H Coils
- Inconel 800 Suppliers in India
- 800HT Inconel Alloy Coil Manufacturers
- 3mm Inconel Alloy 800 Coil
- ASTM B424 800 Inconel Alloy Coils
- T Shaped Inconel Alloy 800HT Coils
- UNS N08810 Coils
- 800 Inconel Alloy Coils
- Incoloy Alloy 800H Manufacturer in Mumbai
- Inconel Alloy 800 Coil Suppliers in India
- 800 Alloy Weight Calculator
- 800HT Inconel Alloy Coil Manufacturers in India
- ASME SB 168 800 Inconel Coil
- 800HT Inconel® Alloy Coil HS Code
- Inconel Alloy Coil Suppliers
- 800 Inconel Hot Rolled Steel Coil
- 800H Alloy Coil
- UNS N08810 Coils
- Alloy 800 Coil Price Today
- 800 Inconel Alloy Suppliers
- Incoloy Flat Coil
- 1.4958 Coils
- Alloy 800HT Coils Supplier in Mumbai
- 800 Nickel Alloy Coil Manufacturers
- Inconel Alloy 800 HR Coil
- Alloy 800H Coil Suppliers in Mumbai
- 800 Incoloy Alloy Manufacturers In India
- Alloy 800H Cold Rolled Coil
- 800 Inconel Alloy Price
- Alloy 800 Coil Manufacturer in India
- Inoloy Alloy 800HT Coil Manufacturer in Mumbai
- 800 Inconel Alloy Slitting Coil
800 Incoloy Alloy Plate Manufacturing Process
Finishes Of 800 Inconel Alloy Plate
| Surface finish | Thickness (mm) | Width (max mm) |
| 2R – Cold rolled, bright annealed plate | 0.25–3.5 | 1524 |
| 2B – Cold rolled, heat treated, pickled, skin passed Sheet | 0.25–8.0 | 2032 |
| 2H – Work hardened plate | 0.4–6.35 | 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled plate | 0.4–8.0 | 2032 |
| 2D – Cold rolled, heat treated, pickled Sheet | 0.4–6.35 | 1524 |
| Polished, brushed plate | 0.5–4.0 | 1524 |
| Surface finish | Gauge (in) | Width (max in) |
| 2D – Cold rolled, heat treated, pickled plate | 12–24 | 60 |
| 2B – Cold rolled, heat treated, pickled, skin passed Plate | 10–24 | 72* |
| Polished Sheet (not brushed) | 11–24 | 60 |
Inconel 800HT Coils Industrial Application
Oil & Gas
Industry
Power Plant
Generation
Marine
Industry
Petrochemical
Industry
Chemical
Industry
Aerospace
Industry
Sugar
Industry
Contact Renox Impex today for a best offer & competitive quotation Of 800 Thin Inconel Alloy Sheets.
